VERSATILE CONFIGURATION
Each of our R-GEN bioprinters is personally configured to specifically meet the needs of our users’ bespoke research goals.
Combine jetting, contact dispensing and electrowriting technologies with a full range of auxiliary process options to build simple or complex cell-laden constructs.
Our scientific advisors are available to guide you to the most suitable and optimal instrument.
KEY FEATURES
INDEPENDENT TEMPERATURE CONTROL
Independent temperature management of each material cartridge, extrusion nozzle temperature and workzone ensures you keep the optimal print conditions.
ELECTRO-SPINNING AND WRITING
All R-GEN instruments are built with the ability to be easily upgraded with electro-spinning and writing technology to allow the creation of micro- and nano-fibers.
EXCHANGEABLE WORKZONES
The instrument modularity gives you the option to easily and quickly change your instrument base plate according to your needs. Select amongst four different workzones to manage temperature in the physiological range or above, to generate micro- and nano-fiber, or to simply print in specific labware.
COMPREHENSIVE INSTRUMENT CONTROL
ADJUST PARAMETER IN REAL TIME
Adjust and refine print parameters any time during the print process.
MONITOR PROTOCOL ACTIONS
Visualize the protocol sequence and action status with the progress tracker.
REDUCE PROTOCOL DEVELOPMENT TIME
Run trial print protocols using rough print parameters, close-up observation and real-time parameter adjustments to quickly identify optimum protocol conditions.
SPECIFICATIONS
Product Name | R-GEN 200 |
---|---|
Description | Biosafe configurable 3D bioprinting station with process interaction and technology convergence. |
Instrument base | A biosafety-enclosed 3D bioprinter, accommodating up to five printing tools with individual temperature control capability, vacuum sample mounting system, four different printing workzones with temperature control options, needle and substrate calibration systems, process supervision system and light curing for in-process material crosslinking. |
Workzone | All print tools able to reach full extent of printing workzone. Max build zone: 130 x 90 x 65 mm |
Control Software | Live process interaction with R-GEN CONTROLLER (e.g. parameter changing, process interruption). |
Safety | Class II Biosafety Enclosure (Type A2) Built-in anti-vibration systems and user safety Ultraviolet germicidal lamp Configurable work bench height Casters Configurable mechanical fixation of display panel (left or right side) |
Installation data | Footprint: 1366 x 963 x 2202 mm |
INSTRUMENT COMPATIBILITY
Ready-to-use tools | Compatible with Pneumatic Strand Dispenser, Pneumatic Drop Dispenser, Pneumatic Melt Dispenser and Volumetric Strand Dispenser. |
---|---|
Workzones | Compatible with Standard Workzone Kit, Physiological Temperature Kit, High Temperature Kits and Electrospinning and Writing Kit. |
Options | Compatible with Light Curing Kit and Process Supervision System. |
Design Software | Compatible with SHAPER planning software for 2D/3D design and bioprinting process and protocol management. |
Third-party products | Compatible with Liquid Temperature Control Unit for cartridges and workzone temperature control. |
